automated Industrial rotating rotary high pressure Parts

automated Industrial rotating rotary high pressure Parts

Aqueous industrial parts washers suitable for washing and degreasing mechanical parts, tools, engine components, implements, moulds and stamped parts.
We offer various models with basket diameters ranging from aprroximately 500 to 1500 mm, covering most typical needs.
If the standard models do not meet your needs, custom rotary basket parts washers can be fabricated. For large or heavy pieces, we recommend rotating platform parts washers.

Features & Details

Rotary Parts Washers are ideal for cleaning parts quickly and efficiently without the need for dangerous solvents. The units were designed with ease of ue, power savings, time savings, and overall cost effectiveness in mind.

The fully enclosed cleaning process includes a rotating basket with high pressure jets of cleaning fluid to efficiently clean parts without wasting production time.

Different length wash cycles can be set depending on the degree of dirt build up.

Standard Features

The Rotary Parts Washers come with the following standard features:

  • Tank floor tilted to drain valve
  • 240-volt power control box
  • Spray bars
  • Forklift compatible
  • Lid seal
  • Heat On light
  • Power On light
  • Insulated cabinet
  • Cycle timer

Parameter

AG SONIC Technical Data Table

MODEL

AG.

550

600

750

900

1150

1500*

Depth

mm

600

705

955

1105

1355

1600

Length

mm

800

885

1035

1185

1470

1600

Height

mm

870

1130

1130

1130

1280

1280

Weight

Kg

50

70

90

120

170

300

Basket Diameter

mm

550

600

750

 900

1150

1500

Working Height

mm

360

450

450

450

550

550

Tank Capacity

L

35

70

90

130

210

250

Basket Load

Kg

15

150

200

200

400

400

Power

V

230

400 3~

400 3~

400 3~

400 3~

400 3~

Pump Power

kW

0.56

0.75

1.85

1.85

2.2

2.2

Pump Flow

Lts/min

50

100

130

130

150

150

Working Pressure

bar

2.4

2.5

3.5

3.5

4.5

4.5



Customized to your design

AG Sonic has been manufacturing ultrasonic parts cleaners for years, providing manufacturers with the highest-quality systems available.

  • Warranty:12 months warranty for AG SONIC ultrasonic cleaner.
  • Lifetime technical support: If any technical problem during warranty time, replacement parts will be sent free of charge.
  • Raw Material Inspection: We source from top suppliers. QC and engineers rigorously inspect raw materials for quality. Cavitation energy aids dirt removal.
  • 100%Product Inspection: QC checks production. Each unit tests 4+ hours pre – pack; sales send inspection pics.
Request Quote

[wpforms id=”13019″]

We Provide high quality products

Why Choose Us

  • Hight quality

  • Fashion designs reasonable & competitive price. fast lead time
  • Professional manufacturer

  • Professional manufacturer. Welcome to visit our website.
  • After Sale Service

  • All products will have been strictly Quality Checked and 2 year warranty,

Frequently Asked Questions

A: Ultrasonic Cleaning is the use of sound waves through water to create microscopic implosions, removing contamination from surfaces, nooks and crannies.

A: The technical process: Ultrasonic energy is introduced into the body of water via transducers.

A: We recommend that you choose the right cleaning agent by the cleaning effect you want to achieve.

A: Most poor cleaning usually results from improper control of one or more process variable(s); such as choosing the wrong detergent solution, insufficient heat, or not allowing enough time for the particular soil to be removed. If you suspect that your ultrasonic cleaner is not cavitating properly, there are two simple tests you can perform: the “glass slide” test and the “foil” test.

A:Rinsing is recommended to remove any chemical residue, which could be harmful to the part. Parts can be rinsed right in your ultrasonic cleaner, using a clean water bath, or in a separate tub containing tap, distilled or deionised water.

A: Heat usually enhances and speeds up the cleaning process, and most detergent solutions are designed to work best at an elevated temperature. The best way to find the optimum temperature, which will give you the fastest, cleanest and safest results, is to run tests. Usually, the best results are within the 50°C to 75°C range.

A: I would definitely recommend, especially the particular unit we have.

A: We did plan originally to get a washer disinfector, but we didn’t think it was worthwhile investment compared to the ultrasonic cleaner.

A:It really speeds up the decontamination process and our staff don’t have hand scrub equipment,.
